Description
xPolyester Cover HMPE Core Jiblines for Digger Derrick Cranes and Utility Winches – Exceptional Strength for Precision Lifting
Our Polyester Cover HMPE Core Jiblines are designed to meet the demands of digger derrick cranes and utility winches, offering superior strength, minimal stretch, and outstanding durability. The HMPE core provides an impressive strength-to-weight ratio, making it ideal for heavy lifting and precision rigging in utility and crane applications. The polyester cover enhances resistance to abrasion, UV rays, and harsh conditions, ensuring these jiblines excel in the toughest environments.
Key Features:
- Ultra-Low Stretch: Guarantees accuracy and control during crane and winch operations.
- HMPE Core: Lightweight yet extremely strong, perfect for heavy-duty tasks.
- Polyester Cover: Provides excellent resistance to wear, weather, and UV damage.
- Versatile Application: Suitable for digger derrick cranes, utility winches, and rigging in the utility industry.
- Built for Tough Conditions: Reliable performance in demanding fieldwork and job site environments.
| Material | Splice: | Diameter inch | Diameter mm | Color | Approx. Weight lbs/100ft. | Approx. Weight kg/100meters | Minimum Breaking Strength Spliced Rope (LBS) |
Minimum Breaking Strength Spliced Rope (Metric Tonnes) |
| Core: HMPE Cover: HT POLYESTER |
Double Braid Class II | 1/2" | 12mm | White with Red/Yellow Tracer | 8.6 | 12.8 | 19,400 | 8,800 |
| Core: HMPE Cover: HT POLYESTER |
Double Braid Class II | 9/16" | 14mm | White with Red/Yellow Tracer | 10 | 14.9 | 28,000 | 12,700 |
| Core: HMPE Cover: HT POLYESTER |
Double Braid Class II | 5/8" | 16mm | White with Red/Yellow Tracer | 12.6 | 18.7 | 33,800 | 15,300 |
| Core: HMPE Cover: HT POLYESTER |
Double Braid Class II | 3/4" | 18mm | White with Red/Yellow Tracer | 16 | 23.8 | 43,800 | 19,900 |
| Core: HMPE Cover: HT POLYESTER |
Double Braid Class II | 7/8" | 22mm | White with Red/Yellow Tracer | 24.8 | 36.9 | 62,500 | 28,400 |
| Core: HMPE Cover: HT POLYESTER |
Double Braid Class II | 1" | 24mm | White with Red/Yellow Tracer | 29.7 | 44.2 | 71,300 | 32,300 |
| Core: HMPE Cover: HT POLYESTER |
Double Braid Class II | 1-1/8" | 28mm | White with Red/Yellow Tracer | 37 | 55.1 | 90,000 | 40,800 |
| Core: HMPE Cover: HT POLYESTER |
Double Braid Class II | 1-1/4" | 30mm | White with Red/Yellow Tracer | 42.6 | 63.4 | 101,000 | 45,800 |
